Function:

Transfering the voltage to a safer control voltage(≤24V)

Secondary short circuit protection by means of a PTC

(low control voltage reduced the risk of electrocution due to envireonmental circumstances

et.:high degree of humidity like outdoors,in a swimming pool compel.etc.).


Feature:

Complete noiseless operation

Full power available at all secondary voltage 4V,8V,12V,24V

Terminals equipped with captive Pozidriv screw,more safety


Application:

Supplying power to a bell circuit(Bells,Buzzers,Door Lock,etc)

Supplying power to the control circuit(impulse switches,relays or contactor for the purpose of control lighting & heating etc.)

Used in distribution board,DIN enclosures,and modular device extension box


Technical Data:

Rated voltage:230/240VAC

Rated frequency:50/60Hz

Electrical strength:4kV

Protection degree:IP20

Consumption:≤1.5W

Rated output current:1A

Standards:IEC/EN 61558-2
